High Capacity V Bank H13 500Pa High Efficiency Air Filter black

Product Description

High Capacity V Bank Hepa Air Filter With Longer Service Life​


Applications:

The FlowMax V2000 HEPA Filter is designed to meet the demanding airflow and efficiency requirements of the most critical applications.

Multipie mini-pleat media packs, assembled into a series of V-banks, permit substatially more media to be contained in the filter - double the media typically found in most HEPA Filters. Maxinum effective media area provides greater airflow capacity, low resistance, high dust holding capacity, and unusually long service life.

The V-bank configuration provides greater airflow capacity and longer service life, while lowering operating costs.

Advantages:

Low energy comsumption and lower operating costs.

Ideal for demanding operating conditions in critical applications.

Longer service life - 398 square feet of media - means fewer changeouts.

High capacity operation with minimum resistance to airflow. 2000 CFM rated airflow at 0.88 in.w.g.

Chemical-resistant ABS frame provides superior strength.

Typical Applications:

FlowMax HEPA filters are ideal for applications operating with higher airflows, up to 600 FPM, and requiring ultra low pressure drop.

• Semiconductor and electronics manufacturing
• Pharmaceutical processing
• Photo film manufacturing / processing
• Hospitals, laboratories, and optical facilities
• Food processing

Materials and Working Conditions:

• Media: Polypropylene or glass fibre paper
• Separator:Hot-melt beads
• Frame: GI;Plastic
• Efficiency range from F9 ,H10,H11,H13(EN 1822)
• Initial resistance: 160 Pa @ 3400 m3/h
• Recommended final pressure drop : 400-500Pa
• Humidity resistance: 100%
• Max Temperature: 80 ℃
• Sealant: Polyurethane rubber PU
• DIN 53438 Flammability: F1
• UL 900 Standard : Class 2
• Max.air flow rate: 125% of rated air flow
• Gasket: one piece half round continuous gasket
• Available in Box or Single flange type.

Specifications:

Other sizes is available!
